⚫ Step 3 Set record type. See Figure 1-34.
⚫ Figure1-34
⚫ When the record type is MD (motion detect), alarm, MD&Alarm, IVS and POS, enable the channel record
function when corresponding alarm occurs. For example, when the alarm type is MD, select Main Menu >
ALARM > VIDEO DETECTION > Motion Detect, select the record channel and enable record function.
See Figure 1-35.
⚫ When the record type is MD (motion detect), alarm, MD&Alarm, IVS and POS, refer to "1.8.5 Video
detect ", "1.8.3 Alarm ", " 1.7.2.4 IVS " and " Step 3 POS " for detailed information.
