30 Chapter 5 SCSI Configuration
The next stage in the installation procedure is to connect your scanner
to the computer.
SCSI configuration involves the following steps:
1.
1.1.
1. Choosing your configuration.
2.
2.2.
2. Installing the SCSI Board (if required).
3.
3.3.
3. Installing the SCSI driver.
4.
4.4.
4. Connecting the scanner to the computer.
5.
5.5.
5. Checking the termination.
6.
6.6.
6. Setting the SCSI ID.
Each step is explained in the relevant section further on.
5.1 Configuration Options
1.
1.1.
1. Set up your scanner less than 6 meters from the computer,
according to one of the configuration options described in the
following pages.
Important: Before connecting the scanner, make sure that the computer,
the scanner, and all other devices are switched OFF.
Instructions for connecting each configuration appear together with
the figure.
