Product Manual – DOC. 8879C DM-NVX-36x(C) Encoders/Decoders • 7
Ethernet 4: SFP port;
Accepts one Crestron SFP-1G Series SFP transceiver module (sold separately);
Green LINK LED indicates Ethernet link status;
Flashing green ACT LED indicates Ethernet activity
USB HOST: USB Type-A connector, female;
USB 2.0 host port;
USB signal extender port for connection to a mouse, keyboard, or other
USB 2.0 device;
1
Available Power: 500 mA at 5 VDC
USB HID: USB Type-A connector, female;
USB 2.0 host port;
USB signal extender port for connection to a mouse, keyboard, or other
USB 2.0 device;
Available Power: 500 mA at 5 VDC
HDMI OUTPUT: HDMI Type A connector, female;
HDMI digital video/audio output (DVI compatible);
2
Green LED indicates video signal transmission at the HDMI output
HDMI INPUT: 19-pin HDMI Type A connector, female;
HDMI digital video/audio inputs (DVI and Dual-Mode DisplayPort™ compatible);
2
Green LED indicates sync detection at the HDMI input
AUDIO I/O: 5-pin 3.5 mm detachable terminal block;
Balanced/unbalanced stereo line-level audio input or output;
Input Impedance: 24k Ohms balanced/unbalanced;
Maximum Input Level: 4 Vrms balanced, 2 Vrms unbalanced;
Output Impedance: 200 Ohms balanced, 100 Ohms unbalanced;
Maximum Output Level: 4 Vrms balanced, 2 Vrms unbalanced
1
The USB DEVICE and USB HOST ports cannot be used simultaneously.
2
HDMI connections require an appropriate adapter or interface cable to accommodate a DVI or Dual-Mode
DisplayPort signal. CBL-HD-DVI interface cables are sold separately.
To Next Page
