Ethernet 2: 8-pin RJ-45 connector, female;
100BASE-TX/1000BASE-T Ethernet port;
Green LED indicates Ethernet link status;
Flashing amber LED indicates Ethernet activity
Ethernet 3: 8-pin RJ-45 connector, female;
100BASE-TX Ethernet port;
Green LED indicates Ethernet link status;
Flashing green LED indicates Ethernet activity;
Amber LED indicates 100BASE-TX link status
Ethernet 4: SFP port;
Accepts one Crestron SFP-1G Series SFP transceiver module (sold separately);
Green LINK LED indicates Ethernet link status;
Flashing green ACT LED indicates Ethernet activity
USB HOST: USB Type-A connector, female;
USB 2.0 host port;
USB signal extender port for connection to a mouse, keyboard, or other
USB 2.0 device;
1
Available Power: 500 mA at 5 VDC
2
USB HID: USB Type-A connector, female;
USB 2.0 host port;
USB signal extender port for connection to a mouse, keyboard, or other
USB 2.0 device;
Available Power: 500 mA at 5 VDC
2
HDMI OUTPUT: HDMI® Type A connector, female;
HDMI digital video/audio output (DVI compatible);
3
Green LED indicates video signal transmission at the HDMI output
HDMI INPUT: 19-pin HDMI Type A connector, female;
HDMI digital video/audio inputs (DVI and Dual-Mode DisplayPort™ compatible);
3
Green LED indicates sync detection at the HDMI input
AUDIO I/O: 5-pin 3.5 mm detachable terminal block;
Balanced/unbalanced stereo line-level audio input or output;
Input Impedance: 24k Ohms balanced/unbalanced;
Maximum Input Level: 4 Vrms balanced, 2 Vrms unbalanced;
Output Impedance: 200 Ohms balanced, 100 Ohms unbalanced;
Maximum Output Level: 4 Vrms balanced, 2 Vrms unbalanced
1
The USB DEVICE and USB HOST ports cannot be used simultaneously.
2
When PoE+ is used to power the DM NVX device, a maximum of 500 ma is available to power both the USB
HOST and USB HID ports. To prevent possible instability issues, it is recommended that the PW-2412WU
power pack (sold separately) be used.
3
HDMI connections require an appropriate adapter or interface cable to accommodate a DVI or Dual-Mode
DisplayPort signal. CBL-HD-DVI interface cables are sold separately.
