CTS HES-3109 Series User Manual

7
Figure 5. Front Panel for 8-Port 10/100/1000Base-T plus 1-Port 1000Base-X or 100/1000Base-X Uplink
Ethernet Managed Switch with CATV RF Module (plastic housing)
Figure 6. Rear Panel for 8-Port 10/100/1000Base-T plus 1-Port 1000Base-X or 100/1000Base-X Uplink
Ethernet Managed Switch with CATV RF & Battery Charging Module (plastic housing)
Figure 7. Front Panel for 8-Port 10/100/1000Base-T plus 1-Port 1000Base-X or 100/1000Base-X Uplink
Ethernet Managed Switch (metal housing)
Figure 8. Rear Panel for 8-Port 10/100/1000Base-T plus 1-Port 1000Base-X or 100/1000Base-X Uplink
Ethernet Managed Switch with Battery Charging Module (metal housing)
All models have the same top, left and right panel.
Figure 9. Top Panel with LEDs (plastic housing) Figure 10. Top Panel with LEDs (metal housing)
10/100/1000Mbps RJ-45 ports
CATV RF (Optional)
1000Mbps F/O port
LED Indicators
CATV RF Input (Optional)
Battery Charging (Optional)
Smart Lighting Control
LED Indicators
10/100/1000Mbps RJ-45 ports
Smart Lighting Control
Grounding Wire
1000Mbps F/O port
Battery Charging (Optional)

CTS HES-3109 Series Specifications

General

Brand	CTS
Model	HES-3109 Series
Category	Switch
Language	English
