7-5
7. OPERATING THE ENGINE
Sc2400 Operator’s Manual
9. Set the throttle control lever about
halfway.
(A) Throttle control lever
(a) To increase the engine speed, pull the throttle
control lever backward.
(b) To decrease the engine speed, push the throttle
control lever forward.
10.Insert the key into the starter key hole
and turn the key to the ON position.
(A) OFF position:
The engine must not run.
(B) ON position:
When the key has been turned to this position,
the engine oil pressure warning light and the
alternator / battery charging light and the engine
coolant warning light will illuminate.
(C) START position:
When the key is turned to this position, the starter
starts turning the flywheel and then the engine
begins to run. Once the engine has started,
release the key.
(A) OFF position
(B) ON position
(C) START position
3014903e
(A)
(b)
(a)
3014907a
(A)
(B)
(C)
To Next Page
