2 — INSTALLATION SPECIFICATIONS AND WIRING
Curtis Model 1351 – December 2018
Return to TOC
pg. 8
Table 2 Low Current Connections
Pin Driver Output Digital Input
Analog Input
(Range)
Special or
Dedicated Usage
Related VCL*
Function References
1 Digital Out 1
Switch Input 13
Virtual Switch 1
Analog 1 (0-5V) Encoder 2B
Automate_Driver( )
Put_Driver( )
Digital_Out_1_State
Switch_13
Analog_1_Volts
Virtual_Switch_1
Encoder_2_RPM
Encoder_2_Position
CSS/1313 HHP Programmer:
Configuration\Outputs\Digital Drivers
Configuration\Inputs\Switches\SW 13
Configuration\Inputs\Virtual Switches\VSW 1
Configuration\Inputs\Analog Inputs
Configuration\Inputs\Encoder Input
2
Switch Input 14
Virtual Switch 2
Analog 2 (0-5V) Encoder 2A Scale_Value( )
Analog_2_Volts
Virtual_Switch_2
Encoder_2_RPM
Encoder_2_Position
CSS/1313 HHP Programmer:
Configuration\Inputs\Switches\SW 14
Configuration\Inputs\Virtual Switches\VSW 2
Configuration\Inputs\Analog Inputs
Configuration\Inputs\Encoder Input
3 CAN 1 Low
Setup_CAN_Transmit_
Mailbox( )
Setup_CAN_
Recieve_Mailbox( ),
Etc.
CSS/1313 HHP Programmer:
Configuration\CAN\Port 1
4 CAN 1 High See CAN 1 Low
CSS/1313 HHP Programmer:
Configuration\CAN\Port 1
5 CAN 2 Low
CSS/1313 HHP Programmer:
Configuration\CAN\Port 2
6 CAN 2 High
CSS/1313 HHP Programmer:
Configuration\CAN\Port 2
7 KSI Keyswitch_Voltage
8 I/O Ground
9 + 12V (Output)
Control_External_
Power()
Ext_12V
Ext_12V_Current
CSS/1313 HHP Programmer:
Configuration\System Controller\External Supplies
To Next Page
