3 — PROGRAMMABLE PARAMETERS
pg. 67
Return to TOC Curtis Model 1351 – December 2018
Analog Output
is adjustable 0-10V output is intended to drive high-impedance loads, such as a battery discharge
indicator or hour meter. e Analog Output can swing from 0-10 volts. e following settings and
monitor value are available for the Analog Output pin.
OUTPUTS — ANALOG OUTPUT
PARAMETER ALLOWABLE RANGE DEFAULT DESCRIPTION
Output Voltage
Analog_11_Volts
0x330A 0x00
0.0 – 20.0 V
0 – 2000
Read Only The present output voltage (state).
This variable is also available in the Monitor menu
Monitor\Outputs\Analog Output\Output Voltage
Analog Out Command
Analog_Out_Command
0x3401 0x00
0 – 100 %
0 – 1000
0.0
0
This adjustable 0-10V output is intended to drive high-impedance
loads, such as a battery discharge indicator or hour meter. The
maximum output (supply) current is approximately 10mA.
0% = Off
100% = 10V
