3 — PROGRAMMABLE PARAMETERS
PROGRAMMABLE PARAMETERS
e 1351 System controller’s programmable parameters enable the user to customize it to the needs
of specic applications even without using VCL. All parameters are programmed over CAN Port1
using the PC-based Curtis Soware Suite
TM
program or the CAN model 1313 handheld programmer
1
.
e 1351 does not support serial-communication programming.
PROGRAMMING MENUS
e programmable parameters are grouped into nested hierarchical menus, as shown in Table 19.
Each menu section has a leading lookup table to locate individual parameters.
Each parameter follows the menu chart format shown below. For every parameter, the menu chart
contain the name, VCL name, and CAN Index. It gives the programming range and the default
setting. Each description explains the parameter. is is where specic features and/or the parameter’s
aects are described in detail.
MENU CHART FORMAT
Individual parameters are presented as follows in the menu charts:
Ramp Up 0 – 10000 ms 8 ms
8
Each driver has ramping functions that are applied
to the command after the pull-in and hold. Following
the initial ramp functions, the ramping is applied to
all changes in the nal driver command. There are
separate parameter values for ramping up and ramping
down the command. Note that the initial pull-in
command value is jumped-to and not ramped.
Driver_1_Ramp_Up_Time 0 – 10000
0x3130 0x00
Parameter name
as it appears in the
Programmer/1313 App
VCL Parameter
name
CAN Object Index
And sub-index
Allowable range
in VCL units.
Allowable range in the
Programmer/1313 App
units
Parameter description and help text.
Parameter function and adjustment guide.
Where applicable, usage suggestions.
Parameter’s
default value in
VCL units
Default parameter value
in Programmer units
1
The Curtis Software Suite™ program is compatible with many leading USB ⇔ CAN interface dongles from Peak, Kvaser, iFAC,
Sondheim, etc.
The CAN model 1313 handheld programmer (1313 HHP) is the blue band Curtis 1313-xx31 Handheld Programmer.
For technical support, and to obtain either of these programming tools, contact the Curtis distributor where you obtained the
1351 system controller or the Curtis sales-support office in your region.
See Appendix C for further information about the programming tools.
