APPENDIX E — 1351 MODELS AND SPECIFICATIONS
Curtis Model 1351 – December 2018
Return to TOC
pg. 138
APPENDIX E — 1351 MODELS AND SPECIFICATIONS
Table E Model Chart and Specications
Item 1351-5001 1351-7001
Voltage 12-48V 36-96V
CAN ports 2
Analog Inputs 11
Dynamic Pot Input 1
RTD Inputs 4
Switch Inputs 14
High Speed Inputs 2
Encoder Inputs 2
PWM Outputs 10
Digital Outputs 3
Half Bridge Outputs 2
Safety Output 1
Analog output 1
External Supply 2
Nominal Input Voltage 12 – 48 Volts 36 – 96 Volts
Minimum Operating Voltage (after startup) 6 Volts 15 Volts
Maximum Operating Voltage 60 Volts 120 Volts
Electrical Isolation to Heatsink 500 Vac 1200 Vac
Storage Ambient Temperature –40 – 85 °C
Operating Ambient Temperature –40 – 50 °C
Package Environmental Rating IP65 as per IEC60529
Weight 0.60 Kg
Dimensions WxLxH 160mm × 125mm × 38.5mm
EMC Designed to the requirements of EN 12895:2015
Safety Designed to the requirements of EN ISO 13849-1:2008
UL
UL recognized component per UL583
