4 — MONITOR VARIABLES
pg. 75
Return to TOC Curtis Model 1351 – December 2018
MONITOR VARIABLES: OUTPUTS PWM Drivers
VARIABLE DISPLAY RANGE DESCRIPTION
Driver 1
PWM
Driver_X_PWM
Monitor variable CAN Index
Driver_X_PWM
1 = 0x3370 0x00
2 = 0x3371 0x00
3 = 0x3372 0x00
4 = 0x3373 0x00
5 = 0x3374 0x00
6 = 0x3375 0x00
7 = 0x3376 0x00
8 = 0x3377 0x00
9 = 0x3378 0x00
10 = 0x3379 0x00
0.0 – 100.0 %
0 – 1000
The driver’s PWM percentage.
Note: Replace X with 1 – 10 for the specic Driver_X_PWM
(See example wiring diagram).
100% equates to the driver being fully ON, meaning 100 percent of the Coil
Return voltage (B+) is applied to the load (e.g., contactor coil). See
the example wiring diagram.
50% equates to an applied voltage of 50%
0 % turns off the driver.
This variable is also located in the Conguration Outputs menu:
Configuration\Outputs\PWM Drivers\Driver X\PWM
Current
Driver_X_Current
Monitor variable CAN Index
Driver_X_Current
1 = 0x3330 0x00
2 = 0x3331 0x00
3 = 0x3332 0x00
4 = 0x3333 0x00
5 = 0x3334 0x00
6 = 0x3335 0x00
7 = 0x3336 0x00
8 = 0x3337 0x00
9 = 0x3338 0x00
10 = 0x3339 0x00
0.000 – 4.000 Amps
0 – 4000
The average current through the Driver.
Note: Replace X with 1 – 10 for the specic Driver_X_Current
(See example wiring diagram).
This variable is also located in the Conguration Outputs menu:
Configuration\Outputs\PWM Drivers\Driver X\Current
MONITOR VARIABLES: OUTPUTS Half-Bridge Drivers
VARIABLE DISPLAY RANGE DESCRIPTION
Driver 11 and 12
PWM
Driver_X_PWM
Monitor variable CAN Index
Driver_X_PWM
11 = 0x337A 0x00
12 = 0x337B 0x00
0.0 – 100.0 %
0 – 1000
The driver’s PWM percentage.
Note: Replace X with 11 or 12 for the specic Driver_X_PWM
Driver 11 = the HB Driver 1 (pin 23)
Driver 12 = the HB Driver 2 (pin 35)
100% equates to the driver being fully ON, meaning 100 percent of the
voltage (B+) is applied to the load (e.g., contactor coil or a motor).
50% equates to an applied voltage of 50%
0 % turns off the driver.
This variable is also located in the Conguration Outputs menu:
Configuration\Outputs\Half-Bridge Drivers\Driver X\PWM
Current
Driver_X_Current
Monitor variable CAN Index
Driver_X_Current
11 = 0x333A 0x00
12 = 0x333B 0x00
0.000 – 4.000 Amps
0 – 4000
The average current through the HB Driver.
Note: Replace X with 11 or 12 for the specic Driver_X_Current
Driver 11 = the HB Driver 1 (pin 23)
Driver 12 = the HB Driver 2 (pin 35)
This variable is also located in the Conguration Outputs menu:
Configuration\Outputs\ Half-Bridge Drivers \Driver X\Current
