3 — PROGRAMMABLE PARAMETERS
Curtis Model 1351 – December 2018
Return to TOC
pg. 36
SYSTEM CONTROLLER — EXTERNAL SUPPLIES
PARAMETER ALLOWABLE RANGE DEFAULT DESCRIPTION
Ext 5V
Ext_5V
0x3325 0x00
0.0 – 10.0 V
0 – 1000
Read Only The measured output voltage at the 5V supply (pin 10)
Ext 12V
Ext_12V
0x3326 0x00
0.0 – 20.0 V
0 – 2000
Read Only The measured output voltage at the 12V supply (pin 9)
Ext 5V Current
Ext_5V_Current
0x3327 0x00
0 – 1000 mA
0 – 1000
Read Only The measured output current at the 5V supply (pin 10)
Note, the combined load current between the +5V and +12V
outputs cannot exceed 300 mA
Ext 12V Current
Ext_12V_Current
0x3328 0x00
0 – 1000 mA
0 – 1000
Read Only The measured output current at the 12V supply (pin 9)
Note, the combined load current between the +5V and +12V
outputs cannot exceed 300 mA
Ext 5V Enable
Low_Power_5V_Mode
0x300B 0x00
0 – 1 (Off/On)
0 – 1
1
1
0 = the 5V supply (pin 10) is Off
1 = the 5V supply (pin 10) is On
Ext 12V Enable
Low_Power_12V_Mode
0x300A 0x00
0 – 1 (Off/On)
0 – 1
1
1
0 = the 12V supply (pin 9) is Off
1 = the 12V supply (pin 9) is On
SYSTEM CONTROLLER — TEMPERATURE
PARAMETER ALLOWABLE RANGE DEFAULT DESCRIPTION
Module Temperature
Module_Temperature
0x3329 0x00
–50.0 – 100.0°C
–500 – 1000
Read Only The internal temperature of the 1531 System Controller
Max Temp
Max_Temp
0x3250 0x00
–50.0 – 100.0°C
–500 – 1000
100.0°C
1000
If the module temperature exceeds this setting, an
Overtemperature fault is issued, an Emergency message sent and
the drivers will be shutdown.
Min Temp
Min_Temp
0x3251 0x00
–50.0 – 100.0°C
–500 – 1000
–20.0°C
–200
If the module temperature falls below this setting, an
Undertemperature fault is issued, an Emergency message sent
and the drivers will be shutdown.
