Curtis Instruments 1351 User Manual

3 — PROGRAMMABLE PARAMETERS
pg. 43
Return to TOC Curtis Model 1351 – December 2018
PARAMETER ALLOWABLE RANGE DEFAULT DESCRIPTION
Active level
Virtual_Switch_X_Active_Level
Parameter’s CAN Index by Switch
No.
5 = 0x31D4 0x00
6 = 0x31D5 0x00
7 = 0x31D6 0x00
8 = 0x31D7 0x00
Low – High
0 – 1
Low
0
When an analog input is used as virtual switch, set the active
level to Low or High (here). Then set the corresponding Analog
Input Low and High Thresholds parameters to match. See:
Programmer » Configuration » Inputs » Analog Inputs » Analog X:
High Threshold
Low Threshold.
X = 5, 6, 7, or 8 for Virtual Switches 5 – 8
VSW 9 and 10: X = Virtual Switch Number which is part of the VCL parameters’ name
Status
Virtual_Switch_X
Variable’s CAN Index by Switch
No.
9 = 0x3388 0x00
10 = 0x3389 0x00
0 – 1
0 – 1
Read Only Virtual Switch X status: On = 1 or Off = 0
The status is also available in the corresponding programmer’s
analog inputs menu and the monitor menu:
Configuration » Inputs » Analog Inputs » Analog X:VSW Status
Monitor » Inputs » Switch Input » Virtual Switch X
X = 9, 10 for Virtual Switches 9 and 10
Open State
Virtual_Switch_X_Open_State
Parameter’s CAN Index by Switch
No.
9 = 0x31C4 0x00
10 = 0x31C5 0x00
Float – Pull Up
0 – 1
Float
0
Do not set the Open State to Pull-Up if this input is used for a
Potentiometer connection
X = 9, 10 for Virtual Switches 9 and 10
Active level
Virtual_Switch_9_Active_Level
Parameter’s CAN Index by Switch
No.
9 = 0x31D8 0x00
10 = 0x31D9 0x00
Low – High
0 – 1
High
1
When an analog input is used as virtual switch, set the active
level to Low or High (here). Then set the corresponding Analog
Input Low and High Thresholds parameters to match. See:
Programmer » Configuration » Inputs » Analog Inputs » Analog X:
High Threshold
Low Threshold.
X = 9, 10 for Virtual Switches 9 and 10
VSW 11
Status
Virtual_Switch_11
0x338A 0x00
0 – 1
0 – 1
Read Only Virtual Switch 11 status: On = 1 or Off = 0 (pin 22)
The status is also available in the corresponding programmer’s
analog inputs menu and the monitor menu:
Configuration » Inputs » Analog Inputs » Analog 11:VSW Status
Monitor » Inputs » Switch Input » Virtual Switch 11
Active level
Virtual_Switch_11_Active_
Level
0x31DA 0x00
Low – High
0 – 1
Low
0
When an analog input is used as a virtual switch, set the active
level to Low or High (here). Then set the corresponding Analog
Input Low and High Thresholds parameters to match. See:
Programmer » Configuration » Inputs » Analog Inputs » Analog 11:
High Threshold
Low Threshold.
INPUTS — VIRTUAL SWITCHES, cont’d
