Curtis Instruments 1351 User Manual

3 — PROGRAMMABLE PARAMETERS
pg. 45
Return to TOC Curtis Model 1351 – December 2018
PARAMETER ALLOWABLE RANGE DEFAULT DESCRIPTION
Analog 5 through 11: X = Analog Input Number which is part of the VCL parameters’ name
Value
Analog_X_Volts
Variable’s CAN Index by Analog Input:
5 = 0x3304 0x00
6 = 0x3305 0x00
7 = 0x3306 0x00
8 = 0x3307 0x00
9 = 0x3308 0x00
10 = 0x3309 0x00
11 = 0x330A 0x00
0.0 – 20.0 V
0 – 2000
Read Only The analog voltage at the specic analog input (See Figure 4)
X = 5 – 11 for the Analog Input 5 – 11: Analog_X_Volts
VSW Status
Virtual_Switch_X
Variable’s CAN Index by Analog Input:
5 = 0x3384 0x00
6 = 0x3385 0x00
7 = 0x3386 0x00
8 = 0x3387 0x00
9 = 0x3388 0x00
10 = 0x3389 0x00
11 = 0x338A 0x00
0 – 1
0 – 1
Read Only Virtual Switch 1 (pin 1) status:
0 = Off
1 = On
X = 5 - 11 for the Analog Inputs 5-11: Virtual_Switch_X
Filter Time Constant
Analog_Input_X_Filter_TC
Parameter’s CAN Index by Analog Input:
5 = 0x3034 0x00
6 = 0x3335 0x00
7 = 0x3336 0x00
8 = 0x3337 0x00
9 = 0x3338 0x00
10 = 0x3339 0x00
11 = 0x333A 0x00
4 – 3000 ms
4 – 3000
8 ms
8
Time to 63% of the full voltage range.
X = 5 – 11 for the Analog Input 5 – 11: Analog_Input_X_
Filter_TC
High Threshold
Analog_Input_X_High_Threshold
Parameter’s CAN Index by Analog
Input:
5 = 0x3024 0x00
6 = 0x3325 0x00
7 = 0x3326 0x00
8 = 0x3327 0x00
9 = 0x3328 0x00
10 = 0x3329 0x00
11 = 0x332A 0x00
0.0 – 20.0 V
0 – 2000
3.0 V
300
For usage of the Virtual Switch input threshold.
Voltages above this ‘set point” are processed as = On
Note the analog input’s corresponding usage;
RTD 1, pin 16, Analog 5
RTD 2, pin 17, Analog 6
RTD 3, pin 18, Analog 7
RTD 4, pin 19, Analog 8
Wiper (potentiometer), pin 20, Analog 9
Pot (potentiometer) High, pin 21, Analog 10
Analog Out, pin 22, Analog 11
X = 5 – 11 for the Analog Input 5 – 11:
Analog_Input_X_High_Threshold
Low Threshold
Analog_Input_X_Low_Threshold
Parameter’s CAN Index by Analog
Input:
5 = 0x3014 0x00
6 = 0x3315 0x00
7 = 0x3316 0x00
8 = 0x3317 0x00
9 = 0x3318 0x00
10 = 0x3319 0x00
11 = 0x331A 0x00
0.0 – 20.0 V
0 – 2000
1.0 V
100
For usage of the Virtual Switch input threshold.
Voltages below this ‘set point” are processed as = Off
Note the analog input’s corresponding usage;
RTD 1, pin 16, Analog 5
RTD 2, pin 17, Analog 6
RTD 3, pin 18, Analog 7
RTD 4, pin 19, Analog 8
Wiper (potentiometer), pin 20, Analog 9
Pot (potentiometer) High, pin 21, Analog 10
Analog Out, pin 22, Analog 11
X = 5 – 11 for the Analog Input 5 – 11:
Analog_Input_X_Low_Threshold
