3 — PROGRAMMABLE PARAMETERS
pg. 69
Return to TOC Curtis Model 1351 – December 2018
PARAMETER ALLOWABLE RANGE DEFAULT DESCRIPTION
Heartbeat Rate
Port_2_Heartbeat_Rate
0x3240 0x00
0 – 4000 ms
0 – 4000
100 Sets the rate at which the CAN heartbeat messages are sent from
the J1939 (port 2) system.
Termination
CAN_2_Termination
0x3003 0x00
Off – Enabled
0 – 1
Off Enables the electronically controlled termination resistor (120 Ω)
for CAN Port 2.
This termination is internal to the 1351, no additional or external
hardware is required.
Cross Connection
CAN_Port_Cross_Connection
0x3004 0x00
Off – Enabled
0 – 1
Off Enable the 2 CAN Ports to be connected together.
Any message received on either Port 1 or Port 2 will be received
by both CAN1 and CAN2. Any message send by CAN 1 or CAN
2 will be sent out both ports. This is often used when CANopen
SRDOs are required in a system.
Note To use this feature, the baud rates of both CAN ports must
be set the same in in order to prevent buss errors and port
shutdowns. The Node IDs of each port must be different.
OUTPUTS — CAN, cont’d
To Next Page
