5 — VEHICLE CONTROL LANGUAGE (VCL)
Curtis Model 1351 – December 2018
Return to TOC
pg. 82
 Set_Watchdog_Fault_Action() User dened actions when the watchdog
timer times-out.
When a watchdog timer times-out, the user-dened actions are launched by the
OS. ese watchdog fault actions are setup in identical fashion to the User Fault
Action in VCL.
 Set_Watchdog_Fault_Action(WD#, Action_Bits)
:
WD# One of the 5 watchdog timers, WD1 through WD5
Action_Bits e following table shows the available action bits
and the predened labels that can be used directly
or combined to make new actions.
Fault Action Name Action Code (Bits)
No Action 0x00000
Shut Down Driver 1 0x00001
Shut Down Driver 2 0x00002
Shut Down Driver 3 0x00004
Shut Down Driver 4 0x00008
Shut Down Driver 5 0x00010
Shut Down Driver 6 0x00020
Shut Down Digital Out 1 0x00040
Shut Down Digital Out 2 0x00080
Shut Down Driver 7 0x00100
Shut Down Driver 8 0x00200
Shut Down Driver 9 0x00400
Shut Down Driver 10 0x00800
Shut Down Driver 11 0x01000
Shut Down Driver 12 0x02000
Shut Down Digital Out 3 0x04000
Shut Down Primary Driver 0x000FF
Shut Down Driver Supervisor 0x07F00
Shut Down Driver All 0x07FFF
Shut Down Ext 5V 0x08000
Shut Down Ext 12V 0x10000*
Shut Down Safety Out 0x20000*
Shut Down All 0x3FFFF*
: None
 :
BAD_ID WD# out of range
PARM_RANGE Parameter (Time) out of range
PT_RANGE Unknown Parameter
*Note: VCL CONSTANTS are limited to 16-Bit, although OS processing is 32-bits. These VCL fault actions, with bits in the upper
word, must be either bit shifted or split & added during VCL runtime, e.g.:
Shut_Down_Ext12V = 0x1 << 16 ; Results in 0x10000
Shut_Down_Safety_Out = 0x2 << 16 ; Results in 0x20000
Shut_Down_All = (0x3<<16) + 0xFFFF ; Results in 0x3FFFF
