7 — DIAGNOSTICS AND TROUBLESHOOTING
pg. 163
Return to TOC Curtis AC F4-A Motor Controller – August 2020
Flash Code Fault Name CAN Index Page
11-5 0xB5 Analog 5 Out Of Range 0x2624
180
11-6 0xB6 Analog 6 Out Of Range 0x2625
11-7 0xB7 Analog 7 Out Of Range 0x2626
11-8 0xB8 Analog 8 Out Of Range 0x2627
11-9 0xB9 Analog 9 Out of Range 0x2628
11-11 0xBB Analog 14 Out Of Range 0x262A
11-12 0xBC Analog Assignment 0x2631
181
11-13 0xBD Analog 18 Out of range 0x262B
11-14 0xBE Analog 19 Out of range 0x262C
12-7 0xC7 Analog 31 Out of Range 0x2106
12-1 0xC1 Branding Error 0x2860
12-3 0xC3 Hardware Compatibility 0x2870
12-5 0xC5 Lift Input 0x2104
12-6 0xC6 Lower Input 0x2105
182
12-10 0xCA Phase PWM Mismatch 0x2101
