Curtis 1298 Manual, OS 11
4a — MONITOR MENU
Monitor Menu: CUTBACKS
DISPLAY
VARIABLE RANGE DESCRIPTION
Motor Temp Cutback 0–100 % Displays the current available as a result of
MotorTempCutback 0–4096 the motor temperature cutback function.
A value of 100% indicates no cutback in
current.
Controller Temp Cutback
0–100 % Displays the current available as a result
ControllerTempCutback 0–4096 the controller temperature cutback function.
A value of 100% indicates no cutback in
current.
Undervoltage Cutback
0–100 % Displays the current available as a result
UndervoltageCutback 0–4096 the undervoltage cutback function.
A value of 100% indicates no cutback in
current.
Overvoltage Cutback
0–100 % Displays the current available as a result
OvervoltageCutback 0–4096 the overvoltage cutback function.
A value of 100% indicates no cutback in
current.
Monitor Menu: MOTOR TUNING
DISPLAY
VARIABLE RANGE DESCRIPTION
Base Speed Captured 0–8000 rpm Displays the value of the motor base speed
Base_Speed_Captured 0–8000 captured in the most recent acceleration.
This value is used to set the Base
Speed parameter (Program
» Motor Control
Tuning
» Field Weakening Control menu),
using the Base Speed set procedure
described on page 62.
