Go to Select Screen
Fluence display and
controls
Memory buttons
STANDBY button
Pulse counter and
reset button
Go to Information &
Adjustment screen
Pulse width display
and controls
Repetition rate
display and controls
Spot size display
and controls
READY button
Temperature display
and controls
12
EXCEL HR OPERATOR MANUAL
D1796, REV. D, 12/16
1064 nm Treatment Screen (STANDBY mode shown)
