45
EXCEL HR OPERATOR MANUAL
D1796, REV. D, 12/16
Physical Parameters
Size (W X D X H): 13 in X 18 in X 38 in (.33 m X .46 m X .96 m)
Weight: 140 lbs (63.5 kg)
Operating length of umbilical: 6.5 ft (2 m)
Minimum bend radius of Storage 5 in (126 mm)
umbilical: Momentary 2 in (50 mm)
Electrical Requirements
Voltage, Current 200 - 240 V~, 30 A
Frequency 50/60 Hz
Environmental Requirements
Temperature Operating 5º C to 30º C
Non-operating -10º C to 50º C, coolant drained
Humidity 0 to 90%, non-condensing
Max. Heat Dissipation 4,000 Watts
Max. Altitude Operating 15,000 ft
Non-operating 50,000 ft
Atmospheric Pressure 20 to 110 kPa
Maximum Allowable Temperature of Accessible Parts
Parts User/Patient Can Touch Material Duration Limits
Enclosure Plastic > 1 min 48º C
Touchscreen Plastic > 1 min 48º C
Handpiece Window Sapphire > 1 min 20º C
Handpiece Treatment Guide Metal > 1 min 20º C
Classifications
FDA Classification Class II Medical Device
CDRH Classification Class IV Laser Product
European MDD 93/42/EEC
Laser Classification Class 4 Laser to IEC 60825-1:2014
Type BF
Applied Part Handpiece
