71
EXCEL HR OPERATOR MANUAL
D1796, REV. D, 12/16
Hair Removal Treatment Guidelines
The following parameters are provided as a guide only and are based on practitioner feedback. Start at
the lowest fluence, and observe laser-tissue interaction and clinical endpoints to determine appropriate
settings.
Skin
T
ype
Window
Temperature
Pulse
Duration
Spot
Size
Fluence
Fine Hair
Fluence
Medium Hair
Fluence
Coarse Hair
I-II 4-8°C 3 ms
14 17-26 J/cm² 13-20 J/cm² 11-17 J/cm²
16 15-23 J/cm² 12-17 J/cm² 10-15 J/cm²
18 13-20 J/cm² 11-14 J/cm² 9-13 J/cm²
III 4°C 3 ms
14 16-21 J/cm² 13-19 J/cm² 11-15 J/cm²
16 14-18 J/cm² 12-16 J/cm² 10-13 J/cm²
18 12-15 J/cm² 11-13 J/cm² 9-11 J/cm²
IV 4°C 3 ms
14 13-17 J/cm² 11-15 J/cm² 9-11 J/cm²
16 12-15 J/cm² 10-13 J/cm² 8-10 J/cm²
18 11-13 J/cm² 9-11 J/cm² 7-9 J/cm²
V 4°C 3 ms
14 10-13 J/cm² 8-11 J/cm² 1064 nm
16 8-11 J/cm² 7-10 J/cm² 1064 nm
18 6-9 J/cm² 6-9 J/cm² 1064 nm
VI – – – 1064 nm 1064 nm 1064 nm
755 nm Wavelength
