Skin
Type
Window
Temperature
Pulse
Duration
Spot
Size
Fluence
Fine Hair
I-II 4-8°C 10-20 ms
10 55-70 J/cm²
12 50-65 J/cm²
15 40-50 J/cm²
18 755 nm
III 4-8°C 10-25 ms
10 50-65 J/cm²
12 45-60 J/cm²
15 40-55 J/cm²
18 755 nm
IV 4°C 10-30 ms
10 45-60 J/cm²
12 40-55 J/cm²
15 30-45 J/cm²
18 755 nm
V 4°C 10-35 ms
10 35-55 J/cm²
12 30-50 J/cm²
15 25-40 J/cm²
18 20-30 J/cm²
VI 4°C 10-40 ms
10 25-45 J/cm²
12 20-40 J/cm²
15 15-35 J/cm²
18 15-30 J/cm²
72
EXCEL HR OPERATOR MANUAL
D1796, REV. D, 12/16
When setting parameters for 1064 nm hair removal treatments, consider the following:
• Coarse Hair
- Longer pulse durations are recommended.
• Fine Hair
- Shorter pulse durations are recommended.
-
Higher fluence may be required to achieve the desired clinical endpoint.
1064 nm Wavelength
