24
EXCEL HR OPERATOR MANUAL
D1796, REV. D, 12/16
Selecting the Repetition Rate
Repetition rate refers to the number of treatment pulses delivered per second and is measured in hertz
(Hz). The repetition rate determines the speed at which you work. Select the desired repetition rate by
pressing the and buttons in the (repetition rate) field.
Location of Repetition Rate Controls and Display on 755 nm Treatment Screen
Selecting the Spot Size
Spot size refers to the size of the treatment spot emitted from the laser handpiece. Select the desired
spot size by pressing the
and buttons in the (spot size) field.
Location of Spot Size Controls and Display on 755 nm Treatment Screen
