CVC TECHNOLOGIES, INC. CVC 310 OPERATION MANUAL
Nickel Type
Type Height
(A)
Type Width
(B)
Type Lines Line Spacing
Character Number
(Max. Length)
Z1.5 1.5 mm 1.8 mm 1~6 4.7 mm
18
(32.4 mm)
Z2.0 2.0 mm 1.8 mm 1~6 4.7 mm
18
(32.4 mm)
Z2.5 2.5 mm 2.2 mm 1~6 4.7 mm
15
(33 mm)
* 2.0mm types are recommended for optimum results.
.
Fig 2.3-3
2 - 5
