CYBELEC DNC 60 PS User Manual

PAGE 8 USER GUIDE DNC 60 PS
P 1 N 1 / 4 CY __
Th: 2.00 45.00 Kg/mm²
p/d 1/ 1 CR __/ri 2.78
--MEM-- --POS-- --COR--
90.0° mes____.__
Y1 293.11 350.92 ____.__
Y2 293.11 351.05 ____.__
L 136.0
X1 133.91 51.85 ____.__
Q ____ ____
Lp 5000 TON 78
Rx _ ___ Ext start _
Vy __% __% ΔT _._s
TDC ___ SP ___
F1:___ F2:___ F3:___ F4:__ F5:__ Cr: 41
EXPLANATION OF THE FIELDS
P
Number of the product in the working memory.
P+
Number of the following product when there is a
sequence of programmes.
N
Bending order (sequence) number to be made
and the total number of bends for the product.
CY
Number of sequence repetitions.
(programmed 0, the sequence is jumped)
Th
Material thickness.
The Greek symbol "Sigma" indicates the tensile
and rupture strength.
This field, as well as those showing the type of
material, can be hidden (see the
preferences page
in the machine parameters).
If this field is hidden, the default value is
steel 45
kg/mm
2
, but other values can be defined in the ad
hoc field in the machine parameters.
p/d
Number of the punch/die pair associated with the
bend to be made.
In the P or D field press
to display the list
of tools.
Select the tool in the list then press
again to
return.
CR/ri
Number of bends requested when working with
ideal curve (min. 4), and internal bending radius.
