ANNEX F: PROGRAMMING WITH L-ALPHA PAGE 51
By pressing the
key, you can consult the PRODUCT; X;
; Y page.
This page displays for each sequence the X and Y axes' values (the
values depend on the used material and tools).
P 1 N 1
N -X- - - -Y- CY
1 305.42 135.0° 233.58 __
2 78.06 90.0° 229.90 __
3 58.06 90.0° 229.90 __ RETURN
4 89.39 135.0° 233.58 __
5 _____.__ ___._° ___.__ 0
6 _____.__ ___._° ___.__ __
Call the sequence page
.
Pass to semi-automatic mode
.
Call the sequence 1.
Execute the first bend.
For corrections, go to page 71.
