CYBELEC DNC 60 PS User Manual

PAGE 86 USER GUIDE DNC 60 PS
PREPARATION
The connection parameters must be the same on the DNC as on the Hyper-
Terminal.
DNC 60 Parameters
PARAMETERS MACHINE -06- Ignore
---- RS232 CHARACTERISTICS
60 Transmission speed 9600
61 Data transmission 8
62 Stop bits 1.0
63 Parity (-:off, 0:even, 1:odd) _
65 Protocol 0
66 BCC 5
67 Locking calculation search K7 _
68 Inch mm conversion
69 Stop Q Part reached _
Protocol: The number of DNC pages printed on a page is indi-
cated in this field.
According to the indicated number, DNC sends a
page-feed to the printer.
Example:
1 = 1 DNC page per printer page.
2 = 2 DNC pages per printer page.
If nothing is programmed, the pages are sent one
after the other.
BCC: this field defines the left margin in characters
(spaces).
left margin= 2 + (BCC x 2)
Field: 0 (2 characters) to 9 (20 characters)
Example: BCC = 4, i.e. 2 + (4 x 2) = 10
LAfter having modified the parameters:
• Go to the TRANSFER page.
• Select 1 then hit the
key to confirm the transmission with the
new parameters, or turn the DNC off and on again.
