EZ-USB Development Kit User Guide, Doc. # 001-66390 Rev. *D 13
Getting Started
Figure 2-7. Keil User Information lnput Window
9. The GPIF designer software is triggered after Keil installation.This software is used to create
State machine waveforms to communicate between the EZ-USB device and devices such as
FPGA, image sensors, FIFO, and so on. If the software is already installed in the PC, then the
installer will not trigger the installation. If the PC does not contain the software, then the GPIF
Designer welcome screen appears, as shown in Figure 2-8. Click Next.
Figure 2-8. GPIF Designer Welcome Window
