xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual
10
5
Example usage:
To configure STP with path cost auto, hellotime 2 seconds, migration enable, and state enable for ports 1 to 2:
DES-3200-28:4#config stp ports 1-2 externalCost auto hellotime 2 migrate yes state enable
Command: config stp ports 1-2 externalCost auto hellotime 2 migrate yes state enable
DES-3200-28:4#
create stp instance_id
Used to creat
e a STP instance ID for MSTP.
Purpose
cre
ate stp instance_id <value 1-8>
Syntax
This
command allows the user to create a STP instance ID for the Multiple Spanning Tree
Protocol. There are five STP instances on the Switch (one internal CIST, unchangeable)
and the user may create up to four instance IDs for the Switch.
Description
Parameters
<value 1-8>  Enter a value between 1 and 8 to identify the Spanning Tree instance on
the Switch.
Only Administrator-level users
can issue this command.
Restrictions
Example usage:
To create a spanning tree instance 2:
DES-3200-28:4#create stp instance_id 2
Command: create stp instance_id 2
Success.
DES-3200-28:4#

D-Link xStack DES-3200 Series Specifications

General

Managed	Yes
Layer	Layer 2
MAC Address Table Size	8K
Quality of Service (QoS)	802.1p
Security Features	ACL, 802.1X, Port Security
Jumbo Frame Support	Up to 9KB
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
Forwarding Rate	13.1 Mpps (48-port)
