xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual
10
6
config stp instance_id
Used to add
or delete an STP instance ID.
Purpose
config
stp instance_id <value 1-8> [add_vlan | remove_vlan] <vidlist>
Syntax
This
command is used to map VIDs (VLAN IDs) to previously configured STP instances on
the Switch by creating an instance_id. A STP instance may have multiple members with the
same MSTP configuration. There is no limit to the number of STP regions in a network but
each region only supports a maximum of five spanning tree instances (one unchangeable
efault entry). VIDs can belong to only one spanning tree instance at a time.
Description
d
Note: Sw
itches in the same spanning tree region having the same STP
instance_id must be mapped identically, and have the same configuration
revision_level number and the same name.
Parameters
<value 1-8>  Enter a number between 1 and 8 to define the instance_id. The Switch
supports five STP instances with one unchangeable default instance ID set as 0.
add_vlan – Along with the vid_range <vidlist> parameter, this command will add VIDs to the
previously configured STP instance_id.
remove_vlan  Along with the vid_range <vidlist> parameter, this command will remove VIDs
to the previously configured STP instance_id.
<vidlist>  Specify the VID range from configured VLANs set on the Switch. Supported VIDs
on the Switch range from ID number 1 to 4094.
Only Administrator-level users
can issue this command.
Restrictions
Example usage:
To configure instance ID 2 to add VID 10:
DES-3200-28:4#config stp instance_id 2 add_vlan 10
Command: config stp instance_id 2 add_vlan 10
Success.
DES-3200-28:4#
Example usage:
To remove VID 10 from instance ID 2:
DES-3200-28:4#config stp instance_id 2 remove_vlan 10
Command: config stp instance_id 2 remove_vlan 10
Success.
DES-3200-28:4#
