D-Link xStack DES-3200 Series

xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual
10
7
delete stp instance_id
Used to delet
e a STP instance ID from the Switch.
Purpose
delete stp in
stance_id <value 1-8>
Syntax
This
command is used to delete a previously configured STP instance ID from the Switch.
Description
Parameters
<value 1-8>  Enter a value between 1 and 8 to identify the Spanning Tree instance on the
Switch.
Only Administrator-level users
can issue this command.
Restrictions
Example usage:
To delete STP instance ID 2 from the Switch.
DES-3200-28:4#delete stp instance_id 2
Command: delete stp instance_id 2
Success.
DES-3200-28:4#
config stp priority
Used to upd
ate the STP instance configuration
Purpose
config
stp priority <value 0-61440> instance_id <value 0-8>
Syntax
This
command is used to update the STP instance configuration settings on the Switch. The
MSTP will utilize the priority in selecting the root bridge, root port and designated port.
Assigning higher priorities to STP regions will instruct the Switch to give precedence to the
selected instance_id for forwarding packets. The lower the priority value set, the higher the
priority.
Description
Parameters
priority <value 0-61440>  Select a value between 0 and 61440 to specify the priority for a
specified instance ID for forwarding packets. The lower the value, the higher the priority. This
entry must be divisible by 4096.
instance_id <value 0-8>  Enter the value corresponding to the previously configured
instance ID of which the user wishes to set the priority value. An instance id of 0 denotes the
default instance_id (CIST) internally set on the Switch.
Only Administrator-level users
can issue this command.
Restrictions
Example usage:
To set the priority value for instance_id 2 as 4096:
DES-3200-28:4#config stp priority 4096 instance_id 2
Command: config stp priority 4096 instance_id 2
Success.
DES-3200-28:4#
