xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual
12
0
Example usage:
To display the multicast MAC address table:
DES-3200-28:4#show multicast_fdb vlan default
Command: show multicast_fdb vlan default
VLAN Name : default
MAC Address : 01-00-5E-00-00-00
Egress Ports : 1-5
Mode : Static
Total Entries : 1
DES-3200-28:4#
show fdb
Used to displ
ay the current unicast MAC address forwarding database.
Purpose
sho
w fdb {port <port> | vlan <vlan_name 32> | vlandid <vidlist> |
mac_address <macaddr> | static | aging_time}
Syntax
This
command is used to display the current contents of the Switch’s
forwarding database.
Description
Parameters
port <port>  The port number corresponding to the MAC destination
address. The Switch will always forward traffic to the specified device
through this port.
<vlan_name 32>  The name of the VLAN on which the MAC address
resides.
<vidlist>  Displays the entries for the VLANs indicated by VID list.
<macaddr>  The MAC address that is present in the forwarding
database table.
static  Displays the static MAC address entries.
aging_time  Displays the aging time for the MAC address forwarding
database.
Non
e.
Restrictions

D-Link xStack DES-3200 Series Specifications

General

Managed	Yes
Layer	Layer 2
MAC Address Table Size	8K
Quality of Service (QoS)	802.1p
Security Features	ACL, 802.1X, Port Security
Jumbo Frame Support	Up to 9KB
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
Forwarding Rate	13.1 Mpps (48-port)
