D-Link xStack DES-3200 Series User Manual

xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual
12
1
Example usage:
To display unicast MAC address table:
DES-3200-28:4#show fdb
Command: show fdb
Unicast MAC Address Ageing Time = 300
VID VLAN Name MAC Address Port Type
---- ------------------------ ----------------- ---- --------
1 default 00-00-51-43-70-00 CPU Self
Total Entries : 1
DES-3200-28:4#
config multicast port_filtering_mode
Used to co
nfigure the multicast packet filtering mode for ports.
Purpose
config multi
cast port_filtering_mode [<portlist> | all]
[forward_unregistered_groups | filter_unregistered_groups]
Syntax
This
command is used to configure the multicast packet filtering
mode for specified ports on the Switch.
Description
[<portli
st> | all] – Enter a port or list of ports for which to configure
the multicast port filtering mode. Entering the all parameter will
denote all ports on the switch.
Parameters
[forward_unregistered_groups | filter_unregistered_groups] – The
user may set the filtering mode to any of these two options.
Only Administrator-level users
can issue this command.
Restrictions
Example usage:
To configure the multicast filtering mode to forward all groups on ports 1 through 4.
DES-3200-28:4#config multicast port_filtering_mode 1-4
forward_unregistered_groups
Command: config multicast port_filtering_mode 1-4
forward_unregistered_groups
Success.
DES-3200-28:4#

D-Link xStack DES-3200 Series Specifications

General

Managed	Yes
Layer	Layer 2
MAC Address Table Size	8K
Quality of Service (QoS)	802.1p
Security Features	ACL, 802.1X, Port Security
Jumbo Frame Support	Up to 9KB
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
Forwarding Rate	13.1 Mpps (48-port)
