xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual
14
9
Example usage:
To delete a VLAN ID on the Switch:
DES-3200-28:4#delete vlan vlanid 5
Command: delete vlan vlanid 5
Success
DES-3200-28:4#
config vlan vlanid
Used to add
additional ports to a previously configured VLAN.
Purpose
config vlan vl
anid <vidlist> { [add [ tagged | untagged | forbidden ] |
delete ] <portlist> | advertisement [enable | disable] | name
<vlan_name 32>} (1)
Syntax
This
command is used to add or delete ports of the port list of
previously configured VLAN(s). Specify the additional ports as being
tagged, untagged or forbidden. The same port is allowed to be an
untagged member port of multiple VLAN’s.
Description
If the ports will join GVRP or not with the advertisement parameter
can also be specified. The name parameter allows the name of the
VLAN that needs to be modified to be specified.
Parameters
<vidlist> Specifies a range of multiple VLAN IDs to be configured.
tagged Specifies the additional ports as tagged.
untagged Specifies the additional ports as untagged.
forbidden Specifies the additional ports as forbidden.
<portlist> A range of ports to add to the VLAN.
advertisement Entering the advertisement parameter specifies if
the port should join GVRP or not. There are two parameters:
enable Specifies that the port should join GVRP.
disable Specifies that the port should not join GVRP.
name Entering the name parameter specifies the name of the
VLAN to be modified.
<vlan_name 32> Enter a name for the VLAN
Only Administrator-level users
can issue this command.
Restrictions
Example usage:
To add an additional port to a previously configured VLAN on the Switch:
DES-3200-28:4#config vlan vlanid 5 add tagged 7 advertisement enable name
RG
Command: config vlan vlanid 5 add tagged 7 advertisement enable name RG
Success.
DES-3200-28:4#
