xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual
16
0
Example usage:
To display Link Aggregation configuration:
DES-3200-28:4#show link_aggregation
Command: show link_aggregation
Link Aggregation Algorithm = MAC-source
Group ID : 1
Type: : TRUNK
Master Port :
Member Port :
Active Port :
Status : Disabled
Flooding Port : 0
Total Entries : 1
DES-3200-28:4#
config lacp_ports
Used to co
nfigure settings for LACP compliant ports.
Purpose
config la
cp_ports <portlist> mode [active | passive]
Syntax
This
command is used to configure ports that have been previously
designated as LACP ports (see create link_aggregation).
Description
Parameters
<portlist> Specifies a port or range of ports to be configured.
mode – Select the mode to determine if LACP ports will process
LACP control frames.
active – Active LACP ports are capable of processing and sending
LACP control frames. This allows LACP compliant devices to
negotiate the aggregated link so the group may be changed
dynamically as needs require. In order to utilize the ability to change
an aggregated port group, that is, to add or subtract ports from the
group, at least one of the participating devices must designate LACP
ports as active. Both devices must support LACP.
passive – LACP ports that are designated as passive cannot process
LACP control frames. In order to allow the linked port group to
negotiate adjustments and make changes dynamically, at one end of
the connection must have “active” LACP ports (see above).
Only Administrator-level users
can issue this command.
Restrictions
Example usage:
To configure LACP port mode settings:
DES-3200-28:4#config lacp_ports 1-12 mode active
Command: config lacp_ports 1-12 mode active
Success.
DES-3200-28:4#
