xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual
21
6
config access_profile
802.1p <value 0-7> Specifies that the access profile will apply only to packets with this
802.1p priority value.
ethernet_type <hex 0x0-0xffff> Specifies that the access profile will apply only to packets
with this hexadecimal 802.1Q Ethernet type value in the packet header.
Parameters
ip Specifies that the Switch will look into the IP fields in each packet.
vlan <vlan_name 32> Specifies that the access profile will only apply to the VLAN with this
name.
vlan_id <vid> Specifies that the access profile will only apply to packets belonging to the
VLAN with this VLAN ID.
source_ip <ipaddr> Specifies that the access profile will apply to only packets with this
source IP address.
destination_ip <ipaddr> Specifies that the access profile will apply to only packets with this
destination IP address.
dscp <value 0-63> Specifies that the access profile will apply only to packets that have
this value in their Type-of-Service (DiffServ code point, DSCP) field in their IP packet
header.
icmp Specifies that the Switch will examine the Internet Control Message Protocol (ICMP)
field within each packet.
type Specifies that the Switch will examine each frame’s ICMP Type field.
code Specifies that the Switch will examine each frame’s ICMP Code field.
igmp Specifies that the Switch will examine the Internet Group Management Protocol
(IGMP) field within each packet.
type – Specifies that the Switch will examine each frame’s IGMP Type field.
tcp Specifies that the Switch will examine the Transmission Control Protocol (TCP) field
within each packet.
src_port <value 0-65535> Specifies that the access profile will apply only to packets that
have this TCP source port in their TCP header.
dst_port <value 0-65535> Specifies that the access profile will apply only to packets that
have this TCP destination port in their TCP header.
flag – Enter the type of TCP flag to be matched.
all: all flags are selected.
urg: TCP control flag (urgent)
ack: TCP control flag (acknowledgement)
psh: TCP control flag (push)
rst: TCP control flag (reset)
syn: TCP control flag (synchronize)
fin: TCP control flag (finish)
udp Specifies that the Switch will examine the Universal Datagram Protocol (UDP) field in
each packet.
src_port <value 0-65535> Specifies that the access profile will apply only to packets that
have this UDP source port in their header.
dst_port <value 0-65535> Specifies that the access profile will apply only to packets that
have this UDP destination port in their header.
protocol_id <value 0-255> Specifies that the Switch will examine the protocol field in each
packet and if this field contains the value entered here, apply the following rules.
ipv6 - Specifies IPv6 filtering mask.
class – Specifies the IPv6 class.
flowlabel – Specifies the IPv6 flow label.
