xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual
21
5
config access_profile
Used to configure an access profile on t
he Switch and to define specific values that will be
used to by the Switch to determine if a given packet should be forwarded or filtered. Masks
entered using the create access_profile command will be combined, using a logical AND
operational method, with the values the Switch finds in the specified frame header fields.
Specific values for the rules are entered using the config access_profile command, below.
Purpose
config a
ccess_profile [profile_id <value 1-512>] [add access_id [auto_assign | <value 1-
65535>] [ethernet {[vlan <vlan_name 32> | vlan_id <vid> ] {mask <hex 0x0-0x0fff>} |
source_mac <macaddr> {mask <macmask>} | destination_mac <macaddr> {mask
<macmask>} | 802.1p <value 0-7> | ethernet_type <hex 0x0-0xffff>} (1) | ip {[vlan <vlan_name
32> | vlan_id <vid>] {mask <hex 0x0-0x0fff>} | source_ip <ipaddr> {mask <netmask> } |
destination_ip <ipaddr> {mask <netmask>} | dscp <value 0-63> | [ icmp {type <value 0-255>
code <value 0-255>} | igmp {type <value 0-255>} | tcp {src_port <value 0-65535> {mask <hex
0x0-0xffff>} | dst_port <value 0-65535> {mask <hex 0x0-0xffff>} | flag [all | { urg | ack | psh | rst |
syn | fin } (1) ] } | udp {src_port <value 0-65535> | dst_port <value 0-65535> } | protocol_id
<value 0-255> } (1) ] } | packet_content {destination_mac <macaddr>{mask<macmask>} |
source_mac <macaddr> {mask <macmask>} | c_tag <hex 0x0-0xffff> {mask <hex 0x0-0xffff>} |
s_tag <hex 0x0-0xffff> {mask <hex 0x0-0xffff>} | offset1 <hex 0x0-0xffff> {mask <hex 0x0-
0xffff>} | offset2 <hex 0x0-0xffff> {mask <hex 0x0-0xffff>} | offset3 <hex 0x0-0xffff> {mask <hex
0x0-0xffff>} | offset4 <hex 0x0-0xffff> {mask <hex 0x0-0xffff>} | offset5 <hex 0x0-0xffff> {mask
<hex 0x0-0xffff>} | offset6 <hex 0x0-0xffff> {mask <hex 0x0-0xffff>} | offset7 <hex 0x0-0xffff>
{mask <hex 0x0-0xffff>} | offset8 <hex 0x0-0xffff> {mask <hex 0x0-0xffff>} | offset9 <hex 0x0-
0xffff> {mask <hex 0x0-0xffff>} | offset10 <hex 0x0-0xffff> {mask <hex 0x0-0xffff>} | offset11
<hex 0x0-0xffff> {mask <hex 0x0-0xffff>} } | ipv6 {class <value 0-255> | flowlabel <hex 0x0-
0xfffff> | source_ipv6 <ipv6addr> {mask <ipv6mask>} | [ tcp {src_port < value 0-65535> {mask
<hex 0x0-0xffff> } | dst_port < value 0-65535>{ mask <hex 0x0-0xffff>}} udp {src_port <value 0-
65535> {mask <hex 0x0-0xffff>} | dst_port <value 0-65535> {mask <hex 0x0-0xffff>}} (1) ]}]
[port [<portlist>|all]] [permit {priority<value 0-7> {replace_priority} | replace_dscp_with <value0-
63>| counter [enable | disable] } | deny | mirror ] { time_range <range_name 32>} | delete
access_id <value 1-65535>]
Syntax
This
command is used to configure an access profile on the Switch and to enter specific values
that will be combined, using a logical AND operational method, with masks entered with the
create access_profile command, above.
Description
Parameters
profile_id <value 1-512> Enter an integer used to identify the access profile that will be
configured with this command. This value is assigned to the access profile when it is
created with the create access_profile command. The profile ID sets the relative priority
for the profile and specifies an index number that will identify the access profile being
created with this command. Priority is set relative to other profiles where the lowest
profile ID has the highest priority. The user may enter a profile ID number between 1
and 512.
add access_id <value 1-65535> Adds an additional rule to the above specified access profile.
The value is used to index the rule created. For information on number of rules that can be
created for a given port, please see the introduction to this chapter.
auto_assign – Choose this parameter to configure the Switch to automatically assign a
numerical value (between 1 and 65535) for the rule being configured.
ethernet Specifies that the Switch will look only into the layer 2 part of each packet.
vlan <vlan_name 32> Specifies that the access profile will only apply to the VLAN with this
name.
vlan_id <vid> Specifies that the access profile will only apply to packets belonging to the
VLAN with this ID.
source_mac <macaddr> Specifies that the access profile will apply to only packets with
this source MAC address.
destination_mac <macaddr> Specifies that the access profile will apply to only packets
with this destination MAC address.
