D-Link xStack DES-3200 Series

xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual
36
3
config lldp ports dot1_tlv_protocol_vid
dot1_tlv_protocol_vid - This TLV optional data type determines whether
the IEEE 802.1 organizationally defined port VLAN ID TLV transmission
is allowed on a given LLDP transmission capable port. The default state
is disabled.
vlanid_list – A list of VIDs to be configured for this command.
Only Administrator-level users
can issue this command.
Restrictions
Example usage
To configure the VLAN name TLV from the outbound LLDP advertisements for all ports:
DES-3200-28:4# config lldp ports all dot1_tlv_pvid enable
Command: config lldp ports all dot1_tlv_pvid enable
Success.
DES-3200-28:4#
config lldp ports dot1_tlv_vlan_name
Used to co
nfigure an individual port or group of ports to exclude one or
more of the IEEE 802.1 Organizational VLAN name TLV data types from
outbound LLDP advertisements.
Purpose
config lld
p ports [<portlist>|all] dot1_tlv_vlan_name [vlan [all |
<vlan_name 32> ] | vlanid <vidlist> ] [enable | disable]
Syntax
This TLV o
ptional data type indicates whether the corresponding Local
System’s VLAN name instance will be transmitted on the port. If a port is
associated with multiple VLANs those enabled VLAN IDs will be
advertised.
Description
<po
rtlist> – Specify a range of ports to be configured.
Parameters
all - To set all ports in the system, use the “all” parameter.
dot1_tlv_vlan_name - This TLV optional data type indicates whether the
corresponding Local System’s VLAN name instance will be transmitted
on the port. If a port is associated with multiple VLANs those enabled
VLAN IDs will be advertised. The default state is disable.
Only Administrator-level users
can issue this command.
Restrictions
Example usage
To configure the VLAN name TLV from the outbound LLDP advertisements for all ports:
DES-3200-28:4# config lldp ports all dot1_tlv_vlan_name vlanid 1-3 enable
Command: config lldp ports all dot1_tlv_vlan_name vlanid 1-3 enable
Success.
DES-3200-28:4#
config lldp ports dot1_tlv_protocol_identity
Used to co
nfigure an individual port or group of ports to exclude one or
more of IEEE 802.1 organization protocol identity TLV data types from
outbound LLDP advertisements.
Purpose
