config lldp ports dot1_tlv_protocol_identity
config lld
p ports [<portlist>|all] dot1_tlv_ protocol_identity [all | {eapol |
lacp | gvrp | stp }] [enable | disable]
Syntax
This TLV o
ptional data type indicates whether the corresponding Local
System's Protocol Identity instance will be transmitted on the port. The
Protocol Identity TLV provides a way for stations to advertise protocols
that are important to the operation of the network. Such as Spanning
Tree Protocol, the Link Aggregation Control Protocol, and numerous
vendor proprietary variations which are responsible for maintaining the
topology and connectivity of the network. If EAPOL, GVRP,
STP(including MSTP), and LACP protocol identity is enabled on this port
and it is enabled to be advertised, then this protocol identity will be
advertised.
Description
<portlist>
- Specify a range of ports to be configured.
Parameters
all - To set all ports in the system, use the “all” parameter.
dot1_tlv_protocol_identity - This TLV optional data type indicates whether
the corresponding Local System's Protocol Identity instance will be
transmitted on the port. The Protocol Identity TLV provides a way for
stations to advertise protocols that are important to the operation of the
network. Such as Spanning Tree Protocol, the Link Aggregation Control
Protocol, and numerous vendor proprietary variations are responsible for
maintaining the topology and connectivity of the network. If EAPOL,
GVRP, STP(including MSTP), and LACP protocol identity is enabled on
this port and it is enabled to be advertised, then this protocol identity will
be advertised. The default state is disable.
Only Administrator-level users
can issue this command.
Restrictions
Example usage
To configure the protocol identity TLV from the outbound LLDP advertisements for all ports:
DES-3200-28:4# config lldp ports all dot1_tlv_protocol_identity all enable
Command: config lldp ports all dot1_tlv_protocol_identity all enable
Success.
DES-3200-28:4#
config lldp ports dot3_tlvs
Used to co
nfigure an individual port or group of ports to exclude one or
more of IEEE 802.3 organization specific TLV data types from outbound
LLDP advertisements.
Purpose
config lldp ports [<portlist
>|all] dot3_tlvs [all |
{mac_phy_configuration_status | link_aggregation | power_via_mdi |
maximum_frame_size}] [enable | disable]
Syntax
Each Spe
cific TLV in this extension can be enabled individually.
Description
<portlist>
- Specifiy a range of ports to be configured.
Parameters
all - To set all ports in the system, use the “all” parameter.
mac_phy_configuration_status - This TLV optional data type indicates
that LLDP agent should transmit 'MAC/PHY configuration/status TLV'.
This type indicates it is possible for two ends of an IEEE 802.3 link to be
configured with different duplex and/or speed settings and still establish
some limited network connectivity. More precisely, the information
