config lldp ports dot3_tlvs
includes whether the port support the auto-negotiation function, whether
the function is enabled, the auto-negotiated advertised capability, and the
operational MAU type. The default state is disabled.
link_aggregation - This TLV optional data type indicates that LLDP agent
should transmit 'Link Aggregation TLV'. This type indicates the current
link aggregation status of IEEE 802.3 MACs. More precisely, the
information should include whether the port is capable of doing link
aggregation, whether the port is aggregated in a aggregated link, and the
aggregated port ID. The default state is disabled.
power_via_mdi - This TLV optional data type indicates that LLDP agent
should transmit 'Power via MDI TLV'. Three IEEE 802.3 PMD
implementations (10BASE-T, 100BASE-TX, and 1000BASE-T) allow
power to be supplied over the link for connected non-powered systems.
The Power via MDI TLV allows network management to advertise and
discover the MDI power support capabilities of the sending IEEE 802.3
LAN station. The default state is disabled.
maximum_frame_size - This TLV optional data type indicates that LLDP
agent should transmit 'Maximum-frame-size TLV. The default state is
disabled.
Only Administrator-level users
can issue this command.
Restrictions
Example usage
To configure the MAC/PHY configuration/status TLV from the outbound LLDP advertisements for all ports:
DES-3200-28:4#config lldp ports a
l
l dot3
_
tlvs mac
_
phy
_
configuration
_
status
enable
Command: config lldp ports all dot3_tlvs mac_phy_configuration_status enable
Success.
DES-3200-28:4#
config lldp forward_message
Used to co
nfigure forwarding of LLDP DU packets when LLDP is
disabled.
Purpose
config lld
p forward_message [enable | disable]
Syntax
Whe
n LLDP is disabled and LLDP forward message is enabled, the
received LLDP DU packets will be forwarded. The default state is
disable.
Description
Non
e.
Parameters
Only Administrator-level users
can issue this command.
Restrictions
Example usage
To configure the LLDP forward LLDPU DU:
