xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual
39
7
config loopdetect ports
Used to co
nfigure the loopback detection function for the port on the Switch.
Purpose
config lo
opdetect ports [ <portlist> | all ] state [ enable | disable ]
Syntax
This
command is used to set up the loopback detection function for port configuration on the
Switch.
Description
<po
rtlist> – Specifies a range of ports to be configured for loopback detection status.
Parameters
all – Apply setting to all ports.
state - Allows loopback detection to be enabled or disabled for the ports specified in the port list.
The default is disabled.
enable – Set port loopback detection status to enable.
disable - Set port loopback detection status to disable.
Only Administrator-level users
can issue this command.
Restrictions
Example usage
To set the loopback detection status to enabled:
DES-3200-28F:4# config loopdetect ports 1-5 state enable
Command: config loopdetect ports 1-5 state enable
Success.
DES-3200-28F:4#

D-Link xStack DES-3200 Series Specifications

General

Managed	Yes
Layer	Layer 2
MAC Address Table Size	8K
Quality of Service (QoS)	802.1p
Security Features	ACL, 802.1X, Port Security
Jumbo Frame Support	Up to 9KB
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
Forwarding Rate	13.1 Mpps (48-port)
