xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual
44
4
The Connectivity Fault Management (CFM) commands in the Command Line Interface (CLI) are listed (along with the
appropriate parameters) in the following table.
Command Parameters
create cfm md <string 22> level <int 0-7>
config cfm md <string 22> { mip [ none | auto | explicit ] | sender_id [ none | chassis | manage |
chassis_manage ] } (1)
create cfm ma <string 22> md <string 22>
config cfm ma <string 22> md <string 22> { vlanid <vlanid 1-4094> | mip [none | auto | explicit | defer] |
sender_id [none | chassis | manage | chassis_manage | defer] | ccm_interval [10ms |
100ms | 1sec | 10sec | 1min | 10min] | mepid_list [add | delete] <mepid_list> }(1)
create cfm mep <string 32> mepid <int 1-8191> md <string 22> ma <string 22> direction [inward | outward]
port <port>
config cfm mep [ mepname <string 32> | mepid <int 1-8191> md <string 22> ma <string 22>] {state [enable
| disable] | ccm [enable | disable] | pdu_priority <int 0-7> | fault_alarm [all | mac_status |
remote_ccm | error_ccm | xcon_ccm | none] | alarm_time < centisecond 250-1000> |
alarm_reset_time < centisecond 250-1000>}(1)
delete cfm mep [mepname <string 32> | mepid <int 1-8191> md <string 22> ma <string 22>]
delete cfm ma <string 22> md <string 22>
delete cfm md <string 22>
enable cfm
disable cfm
config cfm ports
<portlist> state [ enable | disabl
e]
show cfm ports
<portlist>
show cfm { [ md <string 22> { ma <string 22> { mepid <int 1-8191> } } | mepname <string 32> ] }
show cfm fault { md <string 22> { ma <string 22> } }
show cfm port
<port> {level <int 0-7
> | dire
ction [inward | outward] | vlanid <vlanid 1-4094>} cfm loopback <macaddr> [ mepname <string 32> | mepid <int 1-8191> md <string 22> ma <string 22> ]
{num <int 1-65535> | [length <int 0-1500> | pattern <string 1500>] | pdu_priority <int 0-7> }
cfm linktrace <macaddr> [ mepname <string 32> | mepid <int 1-8191> md <string 22> ma <string 22>] {ttl
<int 2-255> | pdu_priority <int 0-7>}
show cfm linktrace [ mepname <string 32> | mepid <int 1-8191> md <string 22> ma <string 22>] { trans_id
<uint>}
delete cfm linktrace { [ md <string 22> { ma <string 22> { mepid <int 1-8191> } } | mepname <string 32> ] }
show cfm mipccm
config cfm mp_ltr_all [ enable | disable ]
show cfm mp_ltr_all
show cfm
remote_mep
[ md <string 22> ma <string 22> mepid <int 1-8191> | mepname <string 32> ]
remote_mepid <int 1-8191>
show cfm pkt_cnt
{ [ ports <portlist> { [ rx | tx
] } | [ rx | tx ] |
ccm ] }
clear cfm pkt_cnt
{ [ ports
<portlist> { [ rx | tx ] } | [ rx | tx
] | ccm ] }
Each command is listed, in detail, in the following sections:
