xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual
44
5
create cfm md
Used to creat
e a maintenance domain for CFM.
Purpose
cre
ate cfm md <string 22> level <int 0-7>
Syntax
Use this com
mand to create a CFM maintenance domain and set the level for that domain.
Description
md <string 2
2> - The new CFM maintenance domain name, each domain should have a unique
name.
Parameters
level <int 0-7> - The level of the CFM domain. Level 7 is the highest level and 0 is the lowest.
Only Administrator-level users
can issue this command.
Restrictions
Example usage:
To create a maintenance domain called “op_domain” and assign a maintenance domain level of “2”:
DES-3200-28F:4# create cfm md op_domain level 2
Command: create cfm md op_domain level 2
Success.
DES-3200-28F:4#
config cfm md
Used to co
nfigure the parameters of a previously created CFM maintenance domain.
Purpose
config
cfm md <string 22> { mip [ none | auto | explicit ] | sender_id [ none | chassis | manage |
chassis_manage ] } (1)
Syntax
Use this com
mand for the creation of maintenance intermediate points (MIP) on the Maintenance
Association (MA) of the specified Maintenance Domain (MD). This is useful to trace the link, MIP
by MIP. It also allows the user to perform a loopback from a CFM maintenance endpoint (MEP) to
an MIP.
Description
md <string 2
2> - The name of the previously created maintenance domain (MD).
Parameters
mip - This will create a maintenance intermediate points (MIP).
none - No MIP is created. This is the default value.
auto – MIPs on the MA of the specified MD can be created on any port in the MD, if the port is not
configured with an MEP of the MD being configured.
For an intermediate switch with the same Maintenance Administration (MA) configuration of the
specific Maintenance Domain (MD), the setting can be automatic for convenient use compared
with the following "explicit" setting.
explicit - MIPs can only be created on a port which has an existing lower level MEP configured on
it AND that port is not configured with an MEP of this MD.
sender_id - This is the control transmission of the sender identifier (ID) Type Length Value (TLV).
none - No sender ID TLV is transmitted. This is the default value.
chassis - Transmit the sender ID TLV with the chassis ID information.
manage - Transmit the sender ID TLV with the managed address information.
chassis_manage - Transmit sender ID TLV with chassis ID information and manage address
information.
Only Administrator-level users
can issue this command.
Restrictions
