xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual
46
5
Example usage:
To enable all MPs to reply to LTM:
DES-3200-28F:4# config cfm mp_ltr_all enable
Command: config cfm mp_ltr_all enable
Success.
DES-3200-28F:4#
show cfm mp_ltr_all
This
command is used to show the current configuration of the "all MPs reply LTRs" function.
Purpose
sho
w cfm mp_ltr_all
Syntax
This
command is used to show the current configuration of the "all MPs reply LTRs" function.
Description
Non
e.
Parameters
Non
e.
Restrictions
Example usage
To view MP reply LTR function status:
DES-3200-28F:4# show cfm mp_ltr_all
Command: show cfm mp_ltr_all
All MPs reply LTRs: Enabled
DES-3200-28F:4#
show cfm remote_mep
This
command is used to display remote MEPs.
Purpose
sho
w cfm remote_mep [ md <string 22> ma <string 22> mepid <int 1-8191> | mepname <string
32> ] remote_mepid <int 1-8191>
Syntax
This
command displays remote MEP information.
Description
ma <string 2
2> - The name of the maintenance association (MA) of the remote MEP to view.
Parameters
md <string 22> - The name of the maintenance domain (MD) of the remote MEP to view.
mepid <int 1-8191> - The MEP identifier of the local MEP
mepname <string 32> The name of the local MEP.
remote_mepid <int 1-8191> - The name of the remote MEP
Non
e.
Restrictions
Example usage:

D-Link xStack DES-3200 Series Specifications

General

Managed	Yes
Layer	Layer 2
MAC Address Table Size	8K
Quality of Service (QoS)	802.1p
Security Features	ACL, 802.1X, Port Security
Jumbo Frame Support	Up to 9KB
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
Forwarding Rate	13.1 Mpps (48-port)
