DACE RT25/50 - Connection for Relay Module

25
OUTPUT DEPENDANT ON VOLTAGE
OF BATTERY FITTED.
ENSURE ALL EXTERNAL DEVICES ARE
CORRECTLY RATED.
MAX. LOAD of 100mA
DACE
Relay Module
DACE
Relay Module
LIGHT
ZONE
BYPASS
L
N
CONNECTION FOR RELAY MODULE
