TECHNICAL SPECIFICATIONS
CONTROLLER SYSTEM
Dual Processor
Main - ARM core - 90 DMIPS
Supply - Microchip - 8 MIPS
Supply Intelligent mul stage dual switch mode
3.5V, 5V, 7V, 13 - 29.4V
Motor Drive Single / Dual H-Bridge 56 Amp
Inputs INF/CLS, INF/OPN, LOCK, TRIG, PED, LOOP, LIGHT, TAMPER, REV1, MARKER1, GSM
Outputs LIGHT, LOCK, ALARM, PULSE, STATUS, MOTOR
Display 8192 pixels (128 x 64)
Audio 16 Ohm 0.25W speaker with English voice prompts and warning messages.
Navigaon Joysck - 5 way
File System FAT (USB interface)
Menu System Graphical Interface with familiar icon navigaon
SUPPLY SYSTEM
Transformer Input Voltage 110V-120V or 220V-240V AC +/- 10%, 50-60Hz (Input voltage is region dependant)
Controller Input Voltage 12V - 24V AC or 17V - 44V DC
Motor Voltage 12V - 24V DC
Motor Supply Baery (12 / 24V) or Transformer driven
Baery Charger Intelligent mul stage charger with automac shutdown, current liming and
power save mode.
12V / 24V auto detect
12V Boost cycle up to 2A @ 14.7V
24V Boost cycle up to 0.8A @ 29.4V
Peak Power Consumpon 37.4W ( 156mA @ 240V )
Typical Power Consumpon Less than 1.7W ( 7mA @ 240V )
Current Consumpon
(motor at rated load)
Up to 20A
COLLISION DETECTION AND PREVENTION
Mulstage Electronic
Collision Detecon
Current, Moon and Supply Sensing
Current Sensing 4 Channels 5 stages each
Moon Sensing 2 Channels 5 stages each (Including dynamic sensing and proling)
Supply Sensing 1 Channel
Infrared Safety Devices Open & close infrared inputs
Beam Self Test On compable devices
Loop Detecon
Yes
An-Crush Zone
Yes
Mul User Mode
Yes
Connues……...
