5-136 MISCELLANEOUS CONTROLS AND OPTIONS
6) Inspection and adjustment of the clutch pedal
Items How to adjust
a. The clutch would not be dis-en-
gaged even though it has been
fully depressed.
b. No resistance is felt on the clutch
pedal even though it has been de-
pressed.
a. Check the oil tank for the clutch master cylinder for
clutch oil level.
b. Bleed air through the air bleeder installed on the clutch
booster.
c. In the event of no effect obtained from the above op-
erations, check if the sealing cup inside the clutch
master cylinder has been damaged, and replace the
clutch master cylinder as required.
Oil tank
Clutch pedal
Clutch master cylinder
MTF0370
