Daewoo Novus M2SEF - External View of Compressor; Specifications of Compressor

5-155 MISCELLANEOUS CONTROLS AND OPTIONS
External view of compressor
1. Oil box 5. Delivery cover 2.
Cylinder 6. Wheel
3. Check valve 7. Delivery pipe 4.
Intake cover 8. Air cleaner
MTF0780
Specifications of compressor
Descriptions
Specifications
Items
Model VS - 715
Type
Delivery capacity
Working pressure
RPM
Flow rate
Overall height/Weight
Overall length/Overall width
Air cooling, oil-free
10m
3
/min
1.9kg/cm
2
800 RPM
3.5L~4.0L
868mm/250kg
830/839mm
