1-13 HOW TO HANDLE THE VEHICLE
2) Peripheral devices of steering column
8
1
2
34
5
6
(1) Differential lock switch(FRT/RR)
(2) Differential lock switch(L/R)
(3) Air conditioning switch
(4) Fog lamp switch
(5) Air parking brake valve
(6) Idle control Knob(for DE/DV Engine)
(7) Front lid opening lever
(8) Side mirror adjusting switch(option)
7
MTS0253
(1) Differential lock switch(FRT/RR)
In the case of two rear axle drive type vehicle, if
either rear axle falls in the mire to cause slip-
page, you must first stop your vehicle and then
place differential lock switch to "ON" position in
order to easily get out of the mire. The warning
buzzer keeps sounding all the while differential
lock is in operation.
MTS0733
(2) Differential lock switch(L/R)
If it is difficult to get your vehicle out of the mire
even by using the differential lock switch which
distributes power to both front and rear axles,
operate the differential lock switch(left/right). If
all the differential lock switches are energized
simultaneously, your vehicle will show a ten-
dency to travel straight. Be careful of this.
MTA0732
Tips for using differential lock system
*
This system cannot be used if the wheels in
connection with the two rear axles are idled
simultaneously.
Caution
Do not exceed 30 seconds for one time use of this
system. If it is not possible to get out of the mire even by
using this system once or twice, do not use it any more.
Your vehicle requires towing. Continuous use of
differential lock system may cause defects to ring
MTA0741 gear set of rear axles and other drive systems.
