5-167 MISCELLANEOUS CONTROLS AND OPTIONS
8. SERVICE ELECTRIC EQUIPMENTS FOR USER
1) Consent for cellular phone charger (12V:
Super deluxe)
If do you want to use of cellular phone charger, you
can connect it to the consent installed below the
cassette tape holder.
MTF1060
Inside the cab
Frame Harness
Cap tilt
2) Harness for working lamp mounting
There is special harness available for working lamp
Working lamp
Auto grease
at the inside and outside of cab.
(1) Fuse: F30, 15A
(2) Special harness available for working lamp
switch is located at the inside pannel of black-
Working lamp
MTF1070
MTF1080
out lamp switch.
(3) Special harness available for working lamp is
located at the inside right frame of cab rear.
Inside the cab Frame Harness 3) Harness for auto cover of dump (option)
There is special harness available for auto cover
of dump at the inside and outside of cab.
(1) Fuse: F28, 20A
(2) Special harness available for auto cover switch
is covered by an electric tape on the main har-
ness at the inside of glove box.
(3) Special harness is located at the right inside end
of frame.
MTF1090 MTF1100
